Cube Camera
Cube Camera
 |
 |
|
|---|---|---|
Model No. |
SP5220W |
SP5220P |
Features |
||
Megapixel/HDTV |
2MP / 720p |
2MP / 720p |
Sensor |
1/3.2" Progressive CMOS |
1/3.2" Progressive CMOS |
Lens |
f=4mm F1.8 fixed |
f=4mm F1.8 fixed |
Day/Night |
Yes (Dual-band Lens) |
Yes (Dual-band Lens) |
LED Illuminators |
IR LED*6, 5M |
IR LED* 6, 5M |
Min Illumination |
Color: 1 lux B/W: 0 lux (IR LED on) |
Color: 1 lux B/W: 0 lux (IR LED on) |
Max Video Resolution |
1600x1200(UXGA) |
1600x1200(UXGA) |
Max Frames Per Second |
1600x1200@15fps 1280x720@30fps |
1600x1200@15fps 1280x720@30fps |
Video Compression |
H.264, MPEG4, MJPEG |
H.264, MPEG4, MJPEG |
Multiple Streams |
2 Streams |
2 Streams |
Networking |
10/100 Ethernet 802.11 b/g/n WLAN |
10/100 Ethernet |
Power Source |
DC 5V |
PoE DC 5V |
Digital In/Out |
- |
- |
Audio In/Out |
Built-in Microphone/3.5mm |
Built-in Microphone/3.5mm |
Memory Card Slot |
MicroSD/SDHC up to 32GB |
MicroSD/SDHC up to 32GB |
Operating Temperature |
0~40° |
0~40° |
Onvif |
- |
- |
Value Added |
-SAT Viewer Web(Cloud Service with p2p Easy Connection) -SAT Viewer Mobile App(QR Code Easy Setup) |
- |
