4M HDR Box IP Camera
4M HDR Box IP Camera
Model No. SP5343R
  • Progressive Scan CMOS Sensor
  • RS485
  • H.264 - 4M/3M/Full HD 1080P/SXGA/HD720P/ XGA/ SVGA/D1/VGA/CIF
4M HDR Box IP Camera
  • Overview
  • Specification
  • Application
  • Download
  • Family
  • FAQ
Micronet SP5343R box IP camera provides high definition video monitoring with superior image quality and detail. It also delivers 4 Megapixel (2688*1520) resolution with excellent color representation and advanced HDR technology for extreme low or high lighting conditions. SP5343R supports quad stream with up to 4 Megapixel high resolution quality, providing variety of streaming options for your surveillance preference..
In addition, C/CS mount lens support and digital I/O port adds more flexibility to meet various installation requirements. 4M HDR cameras are perfect for securing areas where accurate identification is necessary, such as vehicle license plate recognition and facial recognition. These cameras are also suitable for wide area coverage while retaining clear image quality.
  • Multiple Progressive Scan CMOS with 4 Megapixel high resolution live view and recording to see a particular spot in larger and clearer image
  • Multi-exposure HDR for very high quality presence in color and contrast under extreme low or high lighting condition in the background
  • Quad Codec Support such as H.264 Baseline /Main Profile /High Profile/ MJPEG provides efficient bandwidth and save storage space
  • Low Power Consumption on Encoding
  • Privacy Mask keeps the personal spot that does not want to be seen
  • 3D Motion Compensated Noise Reduction (MCTF) reduces the image noise to enhance picture quality
  • Smart Event Function as Audio Detection, Motion Detection, Network Failure Detection and Tampering Alarm
  • ICR allows monitoring at day time and night time
  • Alarm In/Out provides the option of external alarm device for additional alarm alert
  • Audio In/Out provides the option of external audio device to hear and speak
  • PoE 802.3af saves the trouble of a power source
  • Onvif Profile S support
